DC 10W 12V/24V 2~1000RPM Gear Motor.Speed: 5 10 15 20 30 40 50 60 100 120 150 200 300 400 500 1000 RPM.
| Name | Geared DC Motor | Motor outside diameter | Φ37 |
| Model | KM37-30C | Weight | 200g |
| Voltage | DC 12V/24V | Protection class | IP 54 |
| Speed | 2-1000 RPM | Whether the speed adjust | Adjustable speed |
| Power | 10W | Rotate direction | Clockwise or counterclockwise all OK |
| Outside diameter of output shaft | Φ6 | Motor | Brush motor |
| Speed ratio | 516 | 382 | 314 | 221 | 148 | 111 | 95 | 58 | 58 | 47.5 | 40.6 | 31 | 22 | 17.4 | 8.7 | 8.7 | 7.5 |
| Length（L） | 32.5 | 29.5 | 29.5 | 29.5 | 26.5 | 26.5 | 26.5 | 24.5 | 24.5 | 24.5 | 24.5 | 24.5 | 24.5 | 22.5 | 20 | 20 | 20 |
| No-load speed（r/min) | 5 | 10 | 15 | 20 | 30 | 40 | 50 | 60 | 100 | 100 | 120 | 150 | 200 | 300 | 400 | 500 | 1000 |
| Rated speed（r/min) | 3.5 | 7 | 12 | 14 | 21 | 28 | 35 | 42 | 70 | 70 | 84 | 105 | 140 | 210 | 210 | 210 | 210 |
| Rated Torque（kgf.cm) | 22 | 15 | 13.5 | 12 | 11 | 9 | 8 | 4.5 | 3.8 | 3.8 | 3.4 | 3.1 | 2 | 2 | 1.5 | 1.1 | 0.8 |
| DC 12V Rated Current 1A / DC 24V Rated Current 0.6A | |||||||||||||||||
