DC 12V 24V Geared Motor 25W, Model: KM37-555A .Speed: 10 20 30 40 50 70 90 110 170 210 270 410 500 RPM.
| Name | Geared DC Motor | Motor outside diameter | Φ37 |
| Model | KM37-555A | Weight | 330g |
| Voltage | DC 12V/24V | Protection class | IP 54 |
| Speed | 10-500 RPM | Whether the speed adjust | Adjustable speed |
| Power | 25W | Rotate direction | Clockwise or counterclockwise all OK |
| Outside diameter of output shaft | Φ6 | Motor | Brush motor |
| Speed ratio | 310 | 245 | 177 | 133 | 105 | 76 | 57 | 45 | 30 | 24.4 | 19.3 | 12.8 | 10.6 |
| Length（L） | 35.5 | 35.5 | 32.5 | 32.5 | 32.5 | 29.5 | 29.5 | 29.5 | 27.5 | 27.5 | 27.5 | 25.5 | 25.5 |
| No-load speed（r/min) | 10 | 20 | 30 | 40 | 50 | 70 | 90 | 110 | 170 | 210 | 270 | 410 | 500 |
| Rated speed（r/min) | 7 | 14 | 21 | 28 | 35 | 50 | 63 | 77 | 120 | 150 | 190 | 290 | 350 |
| Rated Torque（kgf.cm) | 25 | 25 | 25 | 25 | 25 | 18 | 15 | 11 | 7.6 | 6.7 | 5.2 | 4 | 3.2 |
| Volt DC12V Rated Current 2A / Volt DC24V Rated Current 1.2A / Power 25W | |||||||||||||
