DC 12V 24V Geared Motor 10W, Model: KM37-555A .Speed: 10 20 30 37 50 70 87 100 150 200 350 RPM.
| Name | Geared DC Motor | Motor outside diameter | Φ37 |
| Model | KM37-30C | Weight | 200g |
| Voltage | DC 12V/24V | Protection class | IP 54 |
| Speed | 10-350 RPM | Whether the speed adjust | Adjustable speed |
| Power | 10W | Rotate direction | Clockwise or counterclockwise all OK |
| Outside diameter of output shaft | Φ6 | Motor | Brush motor |
| Speed ratio | 267 | 244 | 172 | 133 | 95 | 73 | 37 | 31.6 | 31.6 | 24 | 13.5 |
| Length（L） | 29.5 | 29.5 | 29.5 | 29.5 | 26.5 | 26.5 | 24.5 | 24.5 | 24.5 | 24.5 | 22.5 |
| No-load speed（r/min) | 10 | 20 | 30 | 37 | 50 | 70 | 87 | 100 | 150 | 200 | 350 |
| Rated speed（r/min) | 7 | 14 | 21 | 25 | 35 | 49 | 60 | 70 | 100 | 140 | 260 |
| Rated Torque（kgf.cm) | 11 | 12 | 11 | 8 | 8 | 4 | 1 | 0.8 | 2 | 1.2 | 0.8 |
| DC 12V Rated Current 1A / DC 24V Rated Current 0.6A / Power 12W | |||||||||||
